So, 2024 Chevy trailboss custom 20-in rims mud tires Factory thinking of adding 2-in spacers any opinions or advice

[Alwaysnewtoys]

Hey boys and girls, so I have a 2024 Chevy trailboss custom,
Options at present:
Factory 20-in rims
Factory mud tires
No mods... thinking of adding 2-in spacers any opinions or advice? I'm thinking 2-in spacers but any pictures of narrower spacers are welcome. I'm just looking to widen the stance so it doesn't look so much like a skateboard. Thanks in advance

Brian G



[NY3Wulf]

This definitely would add stress to the ball joints if that is a concern. Also if you do not have running boards you might be exposing the downstream body panels to more rock projectiles as well as increased sand/snow/salt spray.



[Alwaysnewtoys]

I do have running boards I'm just looking and wondering if maybe just putting a larger Tires on cuz I'm getting all kinds of feedback as to zero offset rims but I would need to do an additional 2-in lift which I'm really not looking to go that radical I just want the shoes to look a little beefier LOL I'm wondering how large/wide I can go without rubbing? Thanks for your response. This definitely would add stress to the ball joints if that is a concern. Also if you do not have running boards you might be exposing the downstream body panels to more rock projectiles as well as increased sand/snow/salt spray.



[Stormin08]

if your looking at a reputable set of spacers... you can get the correct offset wheel for not much more



[Alwaysnewtoys]

So, due to VERY mixed reviews, (mostly negative) no spacers! Without any mod, how tall/wide can I go without tire rubbing? I appreciate the responses/help with this!



[NY3Wulf]

So, due to VERY mixed reviews, (mostly negative) no spacers! Without any mod, how tall/wide can I go without tire rubbing? I appreciate the responses/help with this!

Seems that you can go taller OR wider with no mods. It is trying to go taller AND wider that can cause clearance issues.
There are 2 kinds of "no rubbing" - on-road and then off-road at full articulation. Then there is the type/profile of tire, whether it has squared or tapered shoulders, etc. Then there is the factory rake, which does not seem consistent. Mine has an almost level rake (~0.5") but others seem to have as much as 1.5-2" rake.

I believe ~11.5" wide is about it before you run into risk of hitting UCAs and need different offset rims or spacers. 35" high may be a working tall limit for on-road activity .

I went with 275/65/20 (34.1x10.8) which are no rub at off-road full-articulation but am confident I could have gone 285/65/20 (34.6x11.2) with possible minor off-road rubbing. 295/60/20 (33.9x11.6) may be a possibility for the right tire as well. Different manufacturers, and even models within a brand, can vary in exact dimensions for a given size rating.



[Alwaysnewtoys]

Thanks for all your advice I will definitely be using your information when shopping for tires they don't off-road so I should have plenty of information much appreciated



[NY3Wulf]

tiresize.com is a great site to use



[Stormin08]

when selecting tire size...calculators are a rough round about of the math....

look up the manufacture's actual size chart...

this is a very useful tool for tire size, if take a few measurements....

Rim & Tire Size Calculator. Custom Offsets

Tire Tech Information - The Wheel Fitment, Tyre Stretch, Rolling Radius and Speedometer Error Calculator. Play with specs, try different settings, compare results

www.wheel-size.com



[GETGONE]

I've been running 2" spacers in the winter for 4 years now with no issues on the factory wheels. I run -15mm offset wheels(20x10) in the summer and added fender flares for a beefier look. Without the spacers in the winter it looks dumb with the flares.



[X-BoatCop]

I found this site (below) for info on lifts, offsets, tire height/width, rub, trim, etc, including user submitted photos and specs on their own rides.

I know it's a "commercial" site, to sell tires/wheels, etc., but it's also a good reference site. I have absolutely ZERO connection to it, I've just found some good information and visuals.

Custom Offsets Truck Gallery With Over 100,000 Custom Builds

Explore the Custom Offsets Gallery, the internet's largest fitment database. Search over 100,000 truck builds and counting to see what fits your ride.

www.customwheeloffset.com
